Kingston Tulare CVTAP603222L6-Aqua Eden 60-Inch Acrylic Rectangular 3-Wall Alcove Tub Combo with Waste and Overflow Drain (Left Hand Drain), Glossy White/Polished Nickel

Discover the perfect blend of compactness and functionality with this 60" alcove tub. Despite its smaller size, it offers a generous 17-1/2" water depth, ensuring ample water coverage. Crafted from a combination of smooth, glossy acrylic and durable fiberglass, it combines structural strength with a seamless, low-maintenance aesthetic. The tub features integral tile flanges on all three sides. Embrace the convenience and luxury of this versatile tub, designed to enhance your bathing experience.

Features

• Acrylic construction with fiberglass and resin reinforcement
• Includes brass tip-toe activated waste & overflow
• Alcove installation
• No pre-drilled holes, designed for wall mount tub filler
• Overall dimension: (L)60"x (W)32" x (H)21-5/8"
• Water depth is 14-3/16" to overflow
• 58.2 gallon tub capacity
• Rectangular shape
• 3-wall alcove design
• Left-handed drain placement
• Finished in brilliant glossy white on all exposed sides
• Integral tile flange to prevent water damage
• Ergonomic design for additional comfort and relaxation

Downloads

	Specification Sheet
	Parts Diagram
	Installation Guide

Compatible Parts

Compatible parts and components for this item. Please also ensure each selected additional item is compatible as appropriate.

Drains: DLL206, DLL3166, DLT5301A6, DTL5303A6, DTT206, DTT2166, DTT2186, DTT5302A6, KBU2006, DLL16, DLL18, DLT2086
